Model NO.
PTFE-1230&1580（90*90*10mm)
Price:
US $ 45.99-49.99 / piece
Delivery
EXW，FOB,CIF,DDP,DDU.
Minimum order quantity
1 piece
Supply Ability
100000 piece / Month
Country of Origin
China
Stock Time
7 Days
Quantity:
1.1Antenna
Antenna ModelPTFE-1230&1580（90*90*10mm)
Frequency RangeGPS:L1/L2/L5
BEIDOU:B1/B2/B3
GLONASS:L1/L2
TypeGPS Antenna
Place of OriginChina
Shanghai
Brand Namezxsignal
Gain4.5dBic ：at Zenith
-4.0dBic ：at 20° Elevation
ConnectorSMA
Colorwhite
PolarizationRHCP
Phase Center≤2mm
VSWR2.0
Front-to-rear Ratio≥20dB
CertificationROHS
Axial Ratio≤2.0：at Zenith
≤4.0：at 20° Elevation2.4/5.8GHz WiFi Antenna
Impedance50ohm
1.2 LNA
Frequency RangeGPS:L1/L2/L5
BEIDOU:B1/B2/B3
GLONASS:L1/L2
DC Voltage3.3～9.0V
Gain38±3dB
Out band Rejection
(Absolute value)		≥35dB( FH+100MHz )
≥35dB( FL-100MHz )
Output (VSWR)2.0
Noise Figure(MAX)1.5
DC current≤45mA (40mA@5.0V)
1.3 Overall (Complete module including RF connector)
Frequency RangeGPS;BEIDOU;GLONASS
Output (VSWR)2.0
Gain40dB
Impedance50Ω
  • Model Number：PTFE-1230&1580
  • Brand Name：zxsignal
  • Place of Origin：china
