- Frequency Range:1710-2700MHZ
- Gain:2x14dbi
- Beamwidth- °:H32±5 E: 32±5
- F/B Ratio-dB:≥23
- Polarization:±45
- Nominal Impedance:50 Ω
- VSWR:≤1.5
- Max power-W:100
- Lighting Protect:DC Ground
- Connector:SMA
- Type:2.4GHz & 5GHz Antenna
- Model Number:ZX-25
- Place of Origin:Shanghai,China
- Brand Name:zxsignal
Product Description
All-in-one MIMO antenna kit: Each package contains everything needed to install and use an LTE 4G cellular signal booster antenna, including 2 x 30 feet RG58 cables and N female connectors, and 2 SMA male cable adapters. 2 SMA male to SMA female adapters, 2 TS9 cable adapters and mounting kits (without rod)
Get more gain: This mimo panel antenna provides 2 x 14dBi gain, which helps to enhance signal strength and improve coverage in areas with low coverage, and helps to maintain a stable connection indoors for better Good reception.
Multifunctional home network panel: The mimo panel antenna antenna with SMA connector is very suitable for remote sites with low cellular coverage, and can be installed in most outdoor spaces, including home roofs, utility poles, RVs, trailers, offices, etc.
Extensive network support: Our 4G/LTE panel antennas support a wide frequency range of 170-2700MHz in the United States. This 4G MIMO antenna kit is compatible with Verizon, AT&T, Sprint, T-Mobile, Telus, DigiCel, etc.
Easy to set up and use: Our 4G/LTE phone signal enhancement antennas are made of weatherproof and durable materials, with a sturdy but adjustable mounting bracket, and are equipped with all the connectors you need for your own installation without any hassle
Get more gain: This mimo panel antenna provides 2 x 14dBi gain, which helps to enhance signal strength and improve coverage in areas with low coverage, and helps to maintain a stable connection indoors for better Good reception.
Multifunctional home network panel: The mimo panel antenna antenna with SMA connector is very suitable for remote sites with low cellular coverage, and can be installed in most outdoor spaces, including home roofs, utility poles, RVs, trailers, offices, etc.
Extensive network support: Our 4G/LTE panel antennas support a wide frequency range of 170-2700MHz in the United States. This 4G MIMO antenna kit is compatible with Verizon, AT&T, Sprint, T-Mobile, Telus, DigiCel, etc.
Easy to set up and use: Our 4G/LTE phone signal enhancement antennas are made of weatherproof and durable materials, with a sturdy but adjustable mounting bracket, and are equipped with all the connectors you need for your own installation without any hassle
Specification
item | value |
Model Number | ZX-25 |
Type | 2.4GHz & 5GHz Antenna |
Place of Origin | Shanghai,China |
Brand Name | zxsignal |
Frequency Range | 1710-2700MHZ |
Gain | 2x14dbi |
Beamwidth- ° | H32±5 E: 32±5 |
F/B Ratio-dB | ≥23 |
Polarization | ±45 |
Nominal Impedance | 50 Ω |
VSWR | ≤1.5 |
Max power-W | 100 |
Lighting Protect | DC Ground |
Connector | SMA |
